Custom vacuum chamber

With vast experience in various process chamber and reactor cell design we can prepare custom designs to meet the most demanding processing conditions:
  Specialist in large vacuum chamber (> 200L) fabrication..
  True UHV system (<5E-10 mbar, bakeable to 200 Deg C).
 Optimised chamber designs in relation to conductance and gas loading to ensure the most cost effective pumping system selection.
 Ambient and pressure control systems design to deliver any specific processing conditions i.e. <1ppm O2 or H20.

We will recommend best pumping solutions for your process taking into account your requirements, gas loads and conductance in order to achieve vacuum levels ranging from rough vacuum to UHV.

Exemple of vacuum process chambers  (click to enlarge)

custom vacuum chambers  Large chambers


                            custom vacuum chamber
